Accessories
|
Description |
Part Number |
|
Universal Demand Regulator kit |
10034391 |
|
MSA Link USB dongle |
10082834 |
|
MSA Link Datalogging Software |
10088099 |
|
Shoulder Strap |
474555 |
|
Retractable Line with Belt Clip |
10050976 |
|
Holster, leather |
10099648 |
|
Sampling Probe, flexible 30 cm, conductive |
10103191 |
|
Sampling Line, 1,5 m, conductive |
10103188 |
|
Sampling Line, 3 m, conductive |
10103189 |
|
Sampling Line, 5 m, conductive |
10103190 |
|
Sampling System w/floating probe, 5 m, PU conductive |
10082307 |
|
Sampling Line, 20 m, conductive |
10159430 |
|
Sampling Line, 30 m, conductive |
10159431 |
|
Probe, 1 ft. straight PEEK |
|
|
Probe, 3 ft. straight PEEK |
10042622 |
|
Polyurethane Sample Line, 10 ft. |
10040665 |
|
Polyurethane Sample Line, 25 ft. |
10040664 |
|
Polyurethane Sample Line, 3 ft. Coiled |
10040667 |
|
(Cl2, ClO2, NH3) 5 ft.PU Coiled Sample line & probe, kit |
10105210 |
|
(Cl2, ClO2, NH3) 5 ft. PU Sample line & probe, kit |
10105251 |
|
(Cl2, ClO2, NH3) 10 ft. Teflon Sample line & probe, kit |
10105839 |
|
Replacement Filters for probe, 10 pack |
801582 |
|
Charger only (North America) |
10087913 |
|
Charger only (Global version) |
10092936 |
|
Charging Cradle with Barrier- (North America) |
10093055 |
|
Charging Cradle - (North America) |
10093054 |
|
Charging Cradle (Europe) |
10093057 |
|
Charging Cradle (Australia) |
10093056 |
|
Vehicle Charger Cradle |
10099397 |
|
Cradle Only - (no charger) |
10093053 |
|
ALTAIR 5/5X Multi-Unit Charger, 4 Unit (North American) |
10127427 |
|
ALTAIR 5/5X Multi-Unit Charger, 4 Unit (Europe) |
10127428 |
|
ALTAIR 5/5X Multi-Unit Charger, 4 Unit (UK) |
10127429 |
|
ALTAIR 5/5X Multi-Unit Charger, 4 Unit (Australia) |
10127430 |
|
ALTAIR 5/5X Multi-Unit Charger, 4 Unit No Power Cord |
10128704 |
|
Carrying Case |
10152079 |
NOTE: Not all accessories are available in every local market. Check availability with the local MSA representative .
Replacement Parts
|
No. |
Description |
Part Number |
|
1 |
Case assembly, upper, with label |
10114853 |
|
Case assembly, upper, with label (for Bluetooth version) |
10167493 | |
|
2 |
Battery pack, rechargeable, North America, ALTAIR 5X |
10114835 |
|
Battery pack, rechargeable, EU/Aus, ALTAIR 5X |
10114836 |
|
|
Battery pack, rechargeable, North America, ALTAIR 5X IR |
10114839 |
|
|
Battery pack, rechargeable, EU/Aus, ALTAIR 5X IR |
10114851 |
|
|
3 |
Kit, belt clip replacement, (ALTAIR 5X rechargeable) |
10094830 |
|
Kit, maintenance (includes filters, o-ring, screws) |
10114949 |
|
|
Kit, maintenance, reactive gas (Cl2, ClO2, NH3) (includes filters, o-ring, and screws) |
10114950 |
|
|
4 |
Filter cover assembly |
10083591 |
|
5 |
Display assembly, monochrome |
10111389 |
|
Display assembly, color |
10148366 |
|
|
6 |
Sensor bracket assembly with pump, ALTAIR 5X (includes vibrator motor) |
10114808* |
|
Sensor bracket assembly with pump, ALTAIR 5X IR (includes vibrator motor) |
10114805* |
|
|
7 |
Kit, pump cap replacement |
10114855 |
|
8 |
Sensor, HCN (Series 20) |
10106375 |
|
XCell Sensor, Cl2 |
10106728 |
|
|
Sensor, ClO2 (Series 20) |
10080222 |
|
|
XCell Sensor, SO2 |
10106727 |
|
|
Sensor, NO2 (Series 20) |
10080224 |
|
|
XCell Sensor, NH3 |
10106726 |
|
|
Sensor, PH3 (Series 20) |
10116638 |
|
|
XCell Sensor, COMB |
10106722 |
|
|
XCell Sensor, O2 |
10106729 |
|
|
XCell Sensor, CO |
10106724 |
|
|
XCell Sensor, H2S |
10106723 |
|
|
XCell Sensor, CO-H2S, Two-Tox |
10106725 |
|
|
XCell Sensor, CO/ NO2 |
10121217 |
|
|
XCell Sensor, CO-HC |
10121216 |
|
|
XCell Sensor, H2S-LC/CO |
10121213 |
|
|
XCell Sensor, CO-H2 Res/H2S |
10121214 |
|
|
Sensor, NO (Series 20) |
10114750 |
|
|
XCell Sensor plug |
10105650 |
|
|
20 mm sensor plug |
10088192 |
|
|
9 |
XCell adapter socket |
10110183 |
*In order to replace this item on a detector manufactured prior to July 2022,** additional service to the main PCBA will be required by an MSA Service Center. Contact MSA for additional help. Detectors manufactured July 2022** and afterward may use this item with no further action required.
**The date is located under the serial number in the XYY format.
X = month, A through L. (A = January, B = February, … L = December)
YY = final 2 digits of year.
For example, G22 = July 2022
|
Description |
Part Number |
|
IR sensors - Must be repaired or replaced at a Certified Repair Center |
|
|
IR sensor HC 0-25 % Vol Butane |
10145739-SP |
|
IR sensor HC 0-100 % Vol Methane |
10145752-SP |
|
IR sensor HC 0-100 % Vol Propane |
10145740-SP |
|
IR sensor 0-10 % Vol CO2 |
10145738-SP |
|
IR sensor 0-100% LEL Propane |
10145751-SP |
