Table 24 Housing Specifications

Transmitter Weight:	Short Lid: 6.5 lb.
	Deep Lid: 8.8 lb.
Material Spec:	AISI 316 Stainless Steel

Transmitter Dimensions

Figure 46 ULTIMA X5000 Height & Width

Figure 47 Short Lid Depth

Figure 48 Deep Lid Depth

Figure 49 ULTIMA X5000 Width with XIR PLUS Sensor

Figure 50 ULTIMA X5000 Height & Width with M25 Adapter

Figure 51 Short Lid Depth with M25 Adapter

Figure 52 Deep Lid Depth with M25 Adapter

Figure 53 ULTIMA X5000 Width with XIR PLUS Sensor with M25 Adapter
